→ Our IMS solution is designed to work on any infrastructure layer. Whether you want to deploy the IMS solution on bare metal, on your private cloud or on a public cloud. The solution is also integrated with all types of orchestration layers. Whatever your infrastructure solution is, ng-voice will make it work.
→ Our objective is to lower your voice production costs in 4G/5G networks. Our infrastructure-agnostic IMS is designed to reduce your TCO by at least 80% due to our low resource footprint requiring less hardware than legacy solutions and our high levels of automation, allowing you to run your voice services much more efficiently. In addition, our commercial models are flexible and transparent.
→ We offer an easy-to-operate IMS solution with automated workflows, unparalleled deployment time, and simplified life-cycle-management. Our resource footprint of less than 25 MB per container reduces our resource footprint up to 80% compared to legacy solutions.
The Proxy-CSCF is an edge access function and is the entry point for a UE to request services from an IMS network. This CSCF acts as a proxy by accepting incoming requests and forwarding them to the entity that can service them. Examples of requests include registration and invitation for a multimedia session. ng-voice’s P-CSCF consists of the control component, the media handling component, and session storage components - following a truly cloud-native and microservices approach. Main Features of ng-voice’s P-CSCF
→ Signalling firewall and user identity assertion (P-Preferred-Identity, P-Asserted-Identity header support)
→ Integrity protection and optional encryption based on IPSec
→ Rx-interface towards the PCRF in order to ensure QoS on the mobile network and to achieve the highest quality for Voice- and Video-Calls
Transcoding of the following codecs
→ G711a/u
→ G722
→ AMR
→ AMR-WB
→ and various others
Lawful intercept interfaces: X1, X2, and X3
→ It is fully compliant with 3GPP release 15 and implemented according to 3GPP TS 29.214 and 3GPP TS 24.229
The I-CSCF determines which S-CSCF should be assigned for handling the session requested by the UE. The I-CSCF determines the most suitable serving S-CSCF by inspecting the UE capabilities as well as the capabilities of the available S-CSCFs.
The ng-voice I-CSCF is optimized for speed and minimalist state information is kept in it.
The I-CSCF is compliant with 3GPP release 15 and implemented following the 3GPP Specs TS 29.228, 3GPP TS 29.229 and TS 24.229.
The S-CSCF is responsible for conducting both session control and registration. It is responsible for maintaining the state of sessions and registrations and will trigger applications either provided by ng-voice or by a third party based on the service-profile provided by the HSS and using a 3GPP compliant ISC interface.ng-voice’s S-CSCF consists of the control component and session storage components - following a truly cloud-native and microservices approach.The S-CSCF is compliant with 3GPP release 15 and implemented following the 3GPP Specs TS 29.228, 3GPP TS 29.229, 3GPP TS 24.229 and 3GPP TS 32.229.
The E-CSCF is responsible for retrieving the user-location and locating the closest public safety answering point (PSAP, e.g. policy, fire-brigade or ambulance) for a subscriber. The E-CSCF is compliant to 3GPP release 15. Applicable standards include EENA ng112 and NENA.
The ng-voice BGCF acts as a Gateway between the IMS and other networks. It allows manipulation of the signaling to meet requirements either on the IMS or on the outbound Gateway - in order to simplify Interworking between networks.Main Features of ng-voice’s BGCF
→ Outbound routing based on source-number and destination-prefix
→ Caller-ID and R-URI manipulation for out- and inbound calls
→ Authentication for outbound calls
The BGCF is compliant to 3GPP release 15. Applicable standards include 3GPP TS 24.229.
The ENUM server maps the telephone number of the destination into an URI (Uniform Resource Identifier). The URI is a SIP phone number that identifies the destination network. The ENUM server provides an API for provisioning and an option for bulk uploading provisioning entries. It can provide support for Number portability based on RFC4694.The ENUM is compliant to 3GPP release 15.
The ng-voice AGW is a critical element in telecommunications, designed to secure user authentication and enhance network service delivery. It adheres to 3GPP Release 15 standards, specifically 3GPP TS 33.220, ensuring compliance with global telecom security requirements.
Main Features:
→ GBA Authentication: Integrates with HSS/HLR for secure user authentication, leveraging the Generic Bootstrapping Architecture (GBA) to ensure secure network access.
→ Flexible Operational Modes: Supports redirect and forwarding modes for efficient request handling, facilitating robust traffic management across the network.
→ Application Server Integration: Compatible with various Application Servers for diverse use cases, including header insertion, URL-rewriting, load-sharing, and TAS failover functionalities.
Integration Points:
→ Ua/Ub Interface: Utilises HTTP for communication between the AGW and user equipment (UE), enabling secure session authentication.
→ Ut XCAP Interface: Acts as a reverse proxy for the MMTel XCAP interface over HTTP, supporting user-managed supplementary service configurations.
The ng-voice IP-SM-GW provides SMS interworking between native VoLTE handsets and other networks using a standard MAP protocol. While the SIP protocol is one of the most popular protocols used for voice calls, SS7/MAP (Mobile Application Part) is a widely used protocol for SMS service. MAP is used between the SMSC and IP-SM-GW to allow MO-SM origination and MT-SM delivery over the IMS. CS terminating SMS is also delivered via the SMSC and signalling passes the IP-SM-GW if the SMS originates on IMS. The solution supports S6c diameter interface towards HSS to enable the retrieval of routing information for the transfer of short messages and to report the status of the delivery status of a short message. Together with its “Store and forward” capabilities, it eliminates the requirement for a standalone SMSc in pure 4G/5G networks. The IP-SM-GW is compliant to 3GPP release 15.
The MMTel enhances the telephony service with the following features
→ Call Forwarding (unconditional, busy, not available, timeout)
→ Call Forward Targets (to number or voice box)
→ Call Blocking (inbound, outbound, anonymous call rejection, black-lists, white-lists, matching patterns)
→ CLIP/CLIR
→ Dialling patterns
→ Network announcements through MRF
→ Full feature-set in alignment with GSMA IR.92
Besides talking to the IMS Core and or MRF using the standardized ISc Interface, it provides the following external interfaces:
→ Sh-Interface (Diameter) towards the HSS for storing and retrieving the settings from a centralized HSS
→ Ut-Interface (XCAP) towards the User-Equipment (UE) for configuring the settings directly on the handset
→ It may also integrate with the IT systems via Diameter over the Rf reference point.
The MMTel is compliant to 3GPP release 15. Applicable standards include 3GPP TS 29.328, TS 29.329, TS 24.623, TS 24.607. TS 24.604 and GSMA IR 92.
The ng-voice MRF provides media-related functions such as conferencing and announcements. The ng-voice MRF is a combined MRFC (Media Resource Function Controller) with a MRFP (Media Resource Function Processor).The MRF is compliant to 3GPP release 15. Applicable standards include RFC 4240 and 3GPP TS 24.229.
The ng-voice SCC-AS with SRVCC functionality provides seamless handover from a 4G packet-switched networks towards a legacy 2G/3G circuit switched network as well as T-ADS functionality. In case a handover is requested by the MSC of the 2G/3G network, a voice call towards the Session-Transfer Number (STN-NR) is initiated and the ng-voice SCC-AS initiates an RE-INVITE (for connected sessions) or an UPDATE (for sessions in early stage) to the other party to update the Media-Path for a session, in accordance with RFC 3891. SRVCC is implemented according to 3GPP Release 8. Furthermore, the SCC-AS provides the T-ADS functionality to enable proper domain selection for correct call routing. In ng-voice’s T-ADS solution, calls are terminated by default to ng-voice’s IMS. An IMS registration check of the terminating user determines whether the IMS continues routing the call over IMS or routes the call back to the CS network.
The IMS Platform, as a communications platform carrying voice, fax, and messaging data has to provide means for lawful interception of the content of communication by third-party entities. Law Enforcement Agencies (LEAs) have to be able to connect to the IMS platform in a standardized way — ETSI, 3GPP, and other organizations define the interface (and data exchange) between telecommunication operators and LEAs.
ng-voice provides the X1, X2, X3 interfaces:
X1 – The X1 interface is used by an LI provider to create, modify, delete, and list interceptions on the IMS platform
X2 – The X2 interface is a TLV (Type–length–value) based interface with a simple request/response mechanism over a secure TLS connection, used to pass intercepted signalling data towards an LI provider.
X3 – The X3 interface is also a TLV-based interface with a binary payload encapsulating the intercepted RTP data.
USSD is typically used to provide supplementary services, such as credit-queries and cash-up for prepaid services. It may also be used for any other service, such as interactive news retrieval or any other text-based and interactive service.ng-voice provides a simple to use and easy to integrate USSD-Gateway which allows you to quickly build and integrate USSD-services without having the need to fallback to 2G/3G for using such services. It connects directly to the IMS-Core using a standardized ISc-Interface and can send and retrieve the user input and the responses from and to a subscriber from a web-based service.
Operators who want to supplement LTE coverage by offering VoWiFi to their end-users require the addition of an AAA and ePDG to the Packet Core and IMS. Subscribers can then use WiFi to access EPC networks when LTE coverage is unavailable. As there are different access networks in scope, there is a need for handover between VoLTE and VoWiFi to ensure continuity of services. Hence, the handover function is one of the features of our solution. VoWiFi subscribers use the ePDG to attach to an EPC network and then register with the IMS network. The ePDG interworks with the AAA server to authenticate the UEs. After UE authentication, the ePDG forwards messages to the PGW over the S2b interface.
Main Features of ng-voice's ePDG/AAA
→ The ePDG communicates with the AAA and PGW, providing signaling and data channels for UEs
→ The AAA communicates with the ePDG over the SWm interface to authenticate VoWiFi subscribers
→ The AAA communicates with the PGW over the S6b interface and with the HSS over the SWx interface
The ePDG/AAA is compliant with 3GPP release 17. Applicable standards include 3GPP TS 23.402, TS 33.402, TS 29.273, and TS 29.274.
The PCRF (Policy and Charging Function) dynamically allocates and manages bandwidth requirements for various use cases. For VoLTE/VoNR, it is required to provide a better QoS and, in turn, an excellent user experience. The PCRF provides the QoS authorization that decides how a certain data flow will be treated in the PCRF, typically the PGW, and ensures that this follows the user’s subscription profile.
Main Features of ng-voice's PCRF / P-CSCF
→ Support for the Diameter Gx interface with PGW/GGSN as per 3GPP TS 29.210
→ Support for the Diameter Rx interface with CSCF as per 3GPP TS 29.214
→ Support for Dynamic PCC rules
→ Support for both session and bearer binding as per 3GPP TS 23.203 during IMS default and dedicated bearer setup and teardown
→ Provision of QoS information
→ Support for network-initiated dedicated bearer establishment based on application (e.g., the P-CSCF) request over the Rx interface
→ Support for Network Provided Location Information during IMS call-initiation
The PCRF is compliant with 3GPP release 15. Applicable standards include 3GPP TS 29.212, TS 23.203, TS 29.213, and TS 29.214.
ng-voice provides a software solution for the Home Subscriber Server (HSS), Authentication Centre (AuC), and Equipment Identity Register (EIR) functionalities. ng-voice's subscriber database solution supports 3G, 4G, and 5G technologies and VoLTE, VoNR, and VoWiFi services. The HSS is the System Architecture Evolution (SAE)'s central database in LTE networks where important subscriber information is stored. GSM networks have an Authentication Centre (AuC). The equivalent of this in LTE networks is the HSS. The MME/SGSN communicates with the HSS over the S6a/S6d Diameter interface for authentication, location, and service information about the subscriber. Besides LTE, the HSS is also a functional element of IMS/VoLTE. The HSS database supports the IMS network entities that handle calls/sessions. It contains user profiles, performs authentication and authorization of the user, and can provide their location information. From an IMS perspective, the components communicating with the HSS are the Application Servers (AS) and Call State Control Function servers (CSCFs). Upon being queried by the Interrogating-CSCF (I-CSCF) when SIP registration is performed, the HSS retrieves the Serving-CSCF (S-CSCF) address and assigns it to a user. The user's information and profile data are then downloaded from the backend database and stored by the HSS, where the data can be accessed. After successful authentication on the same interface, the S-CSCF downloads the subscriber's profile over the Cx Diameter interface. The profile contains the Initial Filter Criteria providing the logic to the IMS for triggering SIP messages to the appropriate Application Servers. Application Servers (AS) access the HSS over the Sh diameter interface. Besides public identifiers, IMS user identities, and location information, the HSS also stores repository data related to a service (e.g., Supplementary Service data). Furthermore, the Authentication, Authorization, and Accounting (AAA) function communicates with the HSS over the SWx interface to support non-3GPP access to the network for VoWiFi service. ng-voice's subscriber database solution also provides Authentication Centre (AuC) and Equipment Identity Register (EIR) functionalities. The AuC provides authentication parameters (e.g., authentication vectors) for the authentication process. The EIR provides blacklisting/whitelisting functionalities over the S13 interface. Main Features of ng-voice’s subscriber database solution. Supported interfaces include:
→ S6a and S6d interfaces provide procedures for attaching the device to 3G and 4G packet networks.
→ Cx and Sh interfaces provide procedures for accessing IMS services.- SWx interface providing procedures for VoWiFi access.
→ Zh interface provides authentication procedures for Supplementary Service configuration.
→ The S6c interface provides procedures for SMS operations with the HSS.
→ 5G interfaces including Nhss, NU1, NU2, N70 and N71.
→ SS7 MAP interfaces, including MAP C and MAP D, through an additional interworking function, translating S6d to MAP
→ Authentication procedures included EPS AKA, IMS AKA, and 5G AKA.
→ Provisioning through REST-based APIs.
→ User Management through GUI
→ Robust and geo-redundant backend database
The HSS is compliant to 3GPP release 17. Applicable standards include 3GPP TS 29.228, 3GPP TS 29.229, TS 24.229, TS 29.328 and TS 29.329.Supported interfaces include:
→ S6a and S6d interfaces, which provide procedures for attaching the device to 3G and 4G packet networks
→ Cx and Sh interfaces, which provide procedures for accessing IMS services
→ SWx interface, which provides procedures for VoWiFi access
→ Zh interface, which provides authentication procedures for Supplementary Service configuration
→ S6c interface, which provides procedures for SMS operations with the HSS
→ 5G interfaces, including Nhss, NU1, NU2, N70, and N71
→ SS7 MAP interfaces, including MAP C and MAP D, through an additional interworking function translating S6d to MAP
→ EPS AKA, IMS AKA, and 5G AKA authentication procedures
→ Provisioning through REST-based APIs
→ User Management through GUI
→ Robust and geo-redundant backend database.
ng-voice Container-as-a-Service (CaaS):Unleashing Scalability and Innovation in Telecommunications. At ng-voice, our Container-as-a-Service platform is the backbone of a truly innovative and scalable telecommunications infrastructure. Designed for telecom operators and enterprises alike, our CaaS offering is built on a robust Kubernetes orchestration platform, ensuring your services are always available, scalable, and efficiently managed. Key Features:
→ Managed Kubernetes Platform: Our CaaS is powered by Kubernetes, the leading open-source system for automating deployment, scaling, and management of containerized applications. This ensures you can effortlessly scale your telecom applications to meet demand, reduce operational complexities, and accelerate deployment cycles.
→ Custom CSCF Controllers: Integral to our platform are the CSCF controllers, custom-built by ng-voice to seamlessly manage Call Session Control Function (CSCF) objects within the Kubernetes ecosystem.
Geo-Redundancy and High Availability: Designed with geo-redundancy at its core, our CaaS platform ensures your services remain uninterrupted, with high availability across multiple geographical locations.
→ Seamless Interoperability: Emphasizing interoperability, our platform supports a wide range of telecom applications and services, enabling seamless integration with existing IMS components.
→ Security and Compliance: With built-in security features and adherence to industry compliance standards, our CaaS platform ensures your infrastructure is protected against evolving threats, safeguarding your data and services.
